4-Layer Mixed Pressure Rogers Electronic Communication Productsprototype Pcb

Place of Origin CHINA SHENZHEN
Brand Name JIETENG
Certification UL ROHS ISO9001 TS16949
Model Number Multilayer PCB Fabrication
Minimum Order Quantity 1pcs
Price 0.8-6USD/piece
Packaging Details Blank carton, vacuum packed
Delivery Time 5-8 working day
Payment Terms T/T, Western Union,
Supply Ability 360000 square meters / year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Board Thickness 0.2-3.2mm Material High TG FR4, Halogen Free, Rogers
Copper Thickness 2oz Solder Mask Color Green
Layer Count 4-Layer Surface Finishing HASL,Immersion Gold
Lead Time 7 Working Days After EQ Is Confirmed Dielectric Constant 4.5
Usage Lithium Battery Packs Flammability Rating UL94V-0
Testing AOI Test
High Light

Impedance Control Multilayer PCB Manufacturing

,

Precision Multilayer PCB Manufacturing

Leave a Message
Product Description

Product Description:

Our Surface Finish options for Multi-Level Printed Wiring Board Creation include HASL, ENIG, OSP, Immersion Silver, Immersion Tin, and other finishes as per the customer's request. This ensures that the PCBs are protected from oxidation, corrosion, and other environmental factors that can affect their performance and lifespan.



Features:

Product Name: Multilayer PCB Fabrication
Layer Count: 4
Min. Hole Size: 0.2mm
Min. Line Width: 0.1mm
Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin, Etc.
Solder Mask Color: Green, Blue, White, Black, Red, Etc.
Our Multilayer PCB Fabrication service provides:
Multi-Layer Printed Circuit Board Production
Multi-Layer PCB Component Assembly

Applications:

Applications:
The Multilayer PCB Fabrication product is ideal for various application occasions and scenarios such as:
Automotive Industry - In the automotive industry, the Multilayer PCB Fabrication product can be used to create PCBs for various components such as engine control units, powertrain systems, and infotainment systems. The PCBs can withstand extreme temperatures and vibrations, and they are resistant to moisture, dust, and other contaminants.
Industrial Automation - Industrial automation systems require highly reliable and durable PCBs that can withstand harsh environments. JIETENG's PCB circuit board is designed to meet these requirements and can be used to create multi-layer PCBs for various industrial automation applications such as sensors, controllers, and actuators.
The Multilayer PCB Fabrication product is also suitable for other application scenarios such as aerospace, telecommunications, and military applications. With a minimum hole size of 0.2mm, this product offers high flexibility and versatility, making it an ideal choice for various PCB creation requirements.



Customization:

Our brand, JIETENG, offers high-quality Multi-Layer Printed Circuit Board production services. Our Model Number for this product is PCB circuit board, which is manufactured in our factory in China. We offer customization services to meet specific requirements of our clients.

The Board Thickness of our Multi-Layer Printed Circuit Board Production ranges from 0.2mm to 3.2mm, with Impedance Control for stable signal transmission. Our Min. Line Width is 0.1mm, and the Min. Hole Size is 0.2mm to ensure precision and accuracy.

We offer a variety of Solder Mask Colors including Green, Blue, White, Black, Red, and more. With our Multi-Level Printed Circuit Board Fabrication process, we can provide customized solutions for all your PCB needs.



Packing and Shipping:



Product Packaging:

The Multilayer PCB Fabrication product will be packed securely in anti-static bags and then placed in a sturdy cardboard box with ample padding to protect it during transit. The box will be labeled with the product name and specifications for easy identification.

Shipping:

The Multilayer PCB Fabrication product will be shipped via a reputable courier service such as FedEx or DHL. The shipping cost will be calculated based on the weight and destination of the package. The customer will be provided with a tracking number to monitor the status of their shipment.
