Signal integrity high performance high frequency PCB for communication applications

Place of Origin CHINA SHENZHEN
Brand Name JIETENG
Certification UL ROHS ISO9001 TS16949
Model Number high speed pcb design One-stop PCB Service
Minimum Order Quantity 1pcs
Price 0.2-5USD/piece
Packaging Details Blank carton, vacuum packed
Delivery Time 5-8 working day
Payment Terms T/T, Western Union,
Supply Ability 360000 square meters / year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Test Flying Probe Test Surface Finish HASL, ENIG, OSP,
Min. Hole Size 0.25mm Board Thickness 1.6mm
Material FR4 Hight TG,Tg180 Type Hybrid
Min. Line Width 0.1mm Copper Foil Thickness 4OZ
High Light

White Silkscreen Hybrid Circuit Board

,

0.1mm Hybrid Circuit Board

,

FR4 Hybrid Circuit Board

Leave a Message
Product Description

Product Description:

Our Hybrid Printed Wiring Boards boast a minimum line spacing of 0.1mm.The ability to support dense routing is a key factor for miniaturization, allowing products to become smaller, lighter, and more portable without compromising their performance.
Hybrid Printed Wiring Boards can include a combination of traditional FR4 material with other advanced substrates like polyimide, PTFE (Teflon), or ceramics. This hybridization allows for customized thermal management, improved mechanical strength, and tailored dielectric properties, which are essential for high-power, high-frequency, or temperature-sensitive electronics.As technology continues to evolve, our Hybrid Circuit Board product stands ready to support the next generation of electronic innovations.



Features:

  • Product Name: Hybrid Circuit Board
  • Copper Thickness: 4oz
  • Type: Hybrid
  • Surface Finish: HASL ENIG
  • Board Thickness: 1.6mm
  • Keyword: Hybrid Printed Circuit Boards
  • Keyword: Communication PCB
  • Keyword:High Frequency Rogers PCB


Technical Parameters:

Attribute Specification
Material FR4
Product Name Hybrid Circuit Board
Min. Hole Size 0.25mm
Board Thickness 1.6mm
Test Flying Probe Test
Silkscreen Color White
Surface Finish HASL  ENIG
Min. Line Spacing 0.1mm
Copper Thickness 4oz
Layer 6-Layer


Applications:

The JIETENG Hybrid Circuit Board is a versatile component that is fundamental in the advancement of various high-tech industries. Whether it's in aerospace, medical, consumer electronics, automotive, or telecommunications, the JIETENG PCB circuit board is the backbone of innovation, reliability, and performance.



Packing and Shipping:

The Hybrid Circuit Board is meticulously packaged to ensure its protection during transit. Each board is encased in an anti-static bag, which guards against electrostatic discharges that could damage the sensitive electronic components. The bag is then cushioned with foam inserts that fit snugly within a sturdy, corrugated cardboard box, providing additional shock absorption. To maintain the integrity of the circuit connections, the box is sealed with reinforced tape and clearly marked as 'Fragile' to ensure careful handling.

Our shipping department takes great care to ensure your Hybrid Circuit Board arrives in perfect condition. We use reliable courier services that provide tracking information, so you can monitor your package's journey to your doorstep. Upon dispatch, an email with the tracking details will be sent to you. We recommend inspecting the package upon arrival and contacting us immediately if there are any concerns with the product's condition due to shipping. Our goal is to guarantee that your Hybrid Circuit Board is delivered promptly and securely.
