High Frequency Material Green Solder Mask PCB Board Is Suitable For Equipment Testing

Place of Origin China Shen
Brand Name JIETENG
Certification UL TS16949
Model Number FR4 PCB Board
Minimum Order Quantity 1pcs
Price Negotiable
Packaging Details Blank carton, vacuum packed
Delivery Time 10-12 work days
Payment Terms T/T, Western Union,
Supply Ability 100㎡/day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Layer 6 Min Hole Size 0.2mm
Surface Finish HASL,ENIG Silkscreen Color White
Copper Thickness 1oz Material FR4 HF Material
Board Thickness 1.0mm Type PCB Board
Usage Equipment Testing
Leave a Message
Product Description

Product Description:

Flame retardant printed circuit boards (commonly known as FR4 PCB boards) are indispensable components in electronic devices and systems. Jieteng Circuit's FR4 PCB boards are made of high-quality FR4 HF materials to ensure excellent performance and reliability. Its minimum aperture is 0.2 mm, which is very suitable for various applications that require sophisticated and complex designs.

There are many options for surface treatment of FR4 PCB boards. We usually use HASL (hot air leveling solder) and ENIG (chemical nickel immersion gold), which can provide excellent conductivity and corrosion resistance. At the same time, it enhances the durability and service life of PCBs and has a high position in the industry.

As a PCB board, FR4 PCB boards provide a versatile platform for the design and assembly of electronic circuits. Whether used for consumer electronics, industrial equipment or communication equipment, Jeteng Circuit's PCB boards provide consistent performance and efficiency, meeting the stringent requirements of high-precision standards of test equipment.



Features:

  • Product Name: FR4 PCB Board
  • Solder Mask Color: Green
  • Material: FR4 HF Material
  • Surface Finish: HASL,ENIG
  • Layer: 6
  • Min Hole Size: 0.2mm


Technical Parameters:

Layer 6
Board Thickness 1.0mm
Copper Thickness 1oz
Silkscreen Color White
Type PCB Board
Surface Finish HASL, ENIG
Material FR4 HF Material
Impedance Control Yes
Solder Mask Color Green
Min Hole Size 0.2mm


Applications:

Jieteng's FR4 PCB boards, manufactured in Shenzhen, China, have UL and TS16949 certifications, ensuring their high quality and reliability. With a delivery time of 10-12 working days and a supply capacity of 100 square meters/day, we can provide fast samples for small projects and meet the mass production of large projects.

HASL and ENIG surface treatment options are flexible to meet various needs, and the minimum aperture of 0.2 mm allows for precise and detailed design. Impedance control function further improves the performance of PCB and can perfectly show signal integrity.

As a PCB board, FR4 PCB board is made of FR4 HF material, which is known for its excellent thermal and electrical properties. This makes it suitable for a wide range of application scenarios, including but not limited to:

Consumer electronics: FR4 PCB boards are widely used in devices such as smartphones, tablets and laptops due to their reliability and performance.

Industrial test equipment: With product uniformity and high-quality materials, this board is a popular choice for industrial control systems and test equipment.
Telecommunications: The impedance control and precise design capabilities of FR4 PCB boards make them the top choice for telecommunications infrastructure.
Automotive Electronics: In the automotive industry, where reliability is critical, the boards are used for various electronic systems within the vehicle.



FAQ:

Q. What information is needed for PCB quotation?

A: Gerber files and technical requirements. Such as PCB material, thickness, copper surface, color of mask and silk screen, etc. )

Q. What file formats are accepted for PCB production?

A: Gerber files: CAM350 PCB files: Protel 99SE, PADS, CAD, Altium Designer.

Q. Are my files safe?

A: Your files are completely safe. We protect our customers' intellectual property rights throughout the process. All files of customers will never be shared with any third party.

Q. What is the minimum order quantity?

A: Our company does not have a minimum order quantity. We are able to flexibly handle small and large batches.

Q. How much is the shipping cost?

A: The shipping cost depends on the destination, weight, and packaging size of the goods. If you need us to give you a quote, please let us know.
