White ENIG Surface Treatment Multi-Layer PCB For Aerospace Components
| Place of Origin | China Shen |
|---|---|
| Brand Name | JIETENG |
| Certification | UL IATF16949 |
| Model Number | High frequency circuit board |
| Minimum Order Quantity | 10 pcs |
| Price | Negotiable |
| Packaging Details | Blank carton, vacuum packed |
| Delivery Time | 10-12 work days |
| Payment Terms | Negotiable |
| Supply Ability | 100pcs/day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Legend | White, For Both Side | Surface Finish | ENIG |
|---|---|---|---|
| Raw Material | FR4 HF Material | Certificates | UL, RoHS |
| Application Scenario | Applicable To Aerospace | Thickness Finished | 2.5mm，+/-10% Tolerance |
| Solder Mask Color | Green | ||
| Highlight | Aerospace Components Multi-Layer PCB,ENIG Surface Treatment Multi-Layer PCB |
||
Product Description
Product Description:
The multi-layer printed circuit board has a thickness of 2.5mm and a tolerance of +/-10%. The FR4 HF material used as the raw material of the PCB ensures that it can withstand high temperatures and is resistant to moisture and chemicals, and can continue to work in harsh environments.
The multi-layer printed circuit board has excellent signal integrity and noise reduction, and the ENIG surface treatment ensures a smooth and uniform surface, thereby improving solderability and reliability. It is very suitable for high-performance applications such as telecommunications, medical equipment, and aerospace systems.
Features:
- Product Name: Multi-Layer Printed Circuit Board
- Solder Mask Color: Green
- Application Scenario: Applicable To Aerospace
- Surface Finish: ENIG
- Thickness Finished: 2.5mm, +/-10% Tolerance
- Legend: White, For Both Side
Applications:
The ENIG surface treatment on the JIETENG high-frequency circuit board has excellent conductivity, ensuring that the circuit board performs at its best even in demanding applications. The solder mask is green in color, which has high visibility and allows easy identification of the circuit board in crowded electrical systems. The circuit board is made of FR4 HF material, a high-performance material that is resistant to heat, moisture, and other environmental factors.
The design of the JIETENG high-frequency circuit board is UL and RoHS certified, high quality and reliability, and is ideal for applications that require high-frequency signals, such as radar systems, communication systems, and other advanced electronic devices. With its multi-layer design, the circuit board can easily handle complex electrical systems, providing reliable performance under any conditions, and is designed to meet the needs of the aerospace industry.
FAQ:
Q: What is the brand name of multilayer printed circuit boards?
A: The brand name of multilayer printed circuit boards is Jieteng Circuit Co., Ltd.
Q: What is the certification of multilayer printed circuit boards?
A: Multilayer printed circuit boards are UL IATF16949 certified.
Q: How long is the delivery time of multilayer printed circuit boards?
A: The delivery time of multilayer printed circuit boards is 10-12 working days.
Q. What information is required for PCB quotation?
A: Gerber files and technical requirements. Such as PCB material, thickness, copper surface, mask and silk screen color, etc.
Q. What file formats are accepted for PCB production?
A: Gerber files: CAM350 PCB files: Protel 99SE, PADS, CAD, Altium Designer.
