6-Layer Design, RO4350 High Frequency PCB Is Used In Airport Signal Jammers
| Place of Origin | China Shenzhen |
|---|---|
| Brand Name | JIETENG |
| Certification | UL TS16949 |
| Model Number | High Frequency PCBs |
| Minimum Order Quantity | 5 PCS |
| Price | 15~100 USD |
| Packaging Details | Blank carton, vacuum packed |
| Delivery Time | 10-12working days |
| Payment Terms | Negotiable |
| Supply Ability | 80㎡/day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Board Thickness | 1.8mm | Layer | 6-Layer |
|---|---|---|---|
| Impedance Control | ±10% | Packaging | Vacuum Packing, Bubble Bag, Carton Box, Etc. |
| Copper Thickness | 1OZ | Material | Rogers4350B，FR4 |
| Min Trace Width/Space | 5/5mil | Surface Finish | ENIG |
| Type | High Tg Board High Frequency Rogers 5880 PCB | Solder Mask | Green |
| Usage | Communication PCB， Airport Signal Jammers |
Product Description
Product Description:
High-frequency printed circuit boards (also known as high-frequency PCBs) are high-performance printed circuit boards designed for superior performance in high-frequency applications. With excellent signal integrity and reduced signal loss, they have made great contributions to industries such as telecommunications, aerospace, and medical equipment.
High-frequency PCBs offer a variety of material options to meet specific performance requirements. Commonly used materials for these circuit boards are Rogers4350B, Rogers5880, Rogers4003C, and FR4, etc. The Rogers series is a high-frequency laminate known for its excellent electrical performance and stability, and is the first choice for high-frequency applications. On the other hand, FR4 is a versatile and cost-effective material that is widely used.
Another important feature of high-frequency PCBs is their impedance control, with an error of ±5~10%. This level of control ensures that the board maintains consistent impedance values on different signal traces, thereby minimizing signal distortion and ensuring its reliable performance in high-frequency circuits.
The thickness of this high-frequency PCB from Jieteng Circuit is 1.8 mm. Its durability and flexibility help prevent warping and ensure the structural integrity of the circuit board, making it suitable for demanding high-frequency product applications.
In terms of packaging, high-frequency PCBs are usually carefully packaged to prevent any damage during transportation and handling. Common packaging methods include vacuum packaging, bubble bags, and cartons. These packaging methods help protect the circuit boards from moisture, dust, and other contaminants, ensuring that they are delivered to the end user intact.
Features:
- Product Name: High Frequency PCBs
- Packaging: Vacuum Packing, Bubble Bag, Carton Box, Etc.
- Layer: 6-Layer
- Solder Mask Color: Green
- Surface Finish: ENIG
- Impedance Control: ±5~10%
Technical Parameters:
| Packaging | Vacuum Packing, Bubble Bag, Carton Box, Etc. |
| Material | Rogers4350B,Rogers5880, Rogers4003C,FR4 |
| Impedance Control | ±5~10% |
| Min Hole Size | 0.35mm |
| Copper Thickness | 1OZ |
| Surface Finish | ENIG |
| Layer | 6-Layer |
| Board Thickness | 1.8mm |
| Silk Screen Color | White |
| Min Trace Width/Space | 5/5mil |
FAQ:
Q. What information is needed for PCB quotation?
A: Gerber files and technical requirements. Such as PCB material, thickness, copper surface, color of mask and silk screen, etc. )
Q. What file formats are accepted for PCB production?
A: Gerber files: CAM350 PCB files: Protel 99SE, PADS, CAD, Altium Designer.
Q. Are my files safe?
A: Your files are completely safe. We protect our customers' intellectual property rights throughout the process. All files of customers will never be shared with any third party.
Q. What is the minimum order quantity?
A: Our company does not have a minimum order quantity. We are able to flexibly handle small and large batches.
Q. How much is the shipping cost?
A: The shipping cost depends on the destination, weight, and packaging size of the goods. If you need us to give you a quote, please let us know.
