Surface Mount Technology Process Applicable To Automotive Sensing Electronic Devices

Product Description:

The SMT assembly service provided by Jieteng Circuit Co., Ltd. is a comprehensive solution for your electronic manufacturing needs. With rich capabilities and expertise, we are able to provide first-class assembly services to meet your needs.

First, our SMT assembly facility services can handle a variety of circuit board thicknesses, ranging from 0.4mm to 5.0mm.

Secondly, in terms of components, our services cover passive and active components. From resistors and capacitors to integrated circuits and transistors, we can handle a variety of components, including BGA, QFN, SOP, PLCC, SOIC, etc. Whether it is a complex component or a standard component, our experienced technicians will handle it carefully.

Features:

• Product Name: SMT Assembly Service
• Surface Finish: Immersion Gold
• Components Type: BGA, QFN, SOP, PLCC, SOIC, Etc.
• Manufacturing Process: Surface Mount Technology (SMT)
• Board Thickness: 0.4-5.0mm

Technical Parameters:

Applications:

Originated from Shenzhen, China, Jieteng's SMT assembly service provides flexible solutions to meet the needs of various product applications and scenarios. The service has been UL certified to ensure quality and reliability across industries and applications.

Surface Mount Maintenance Service: Jettron’s SMT assembly service is ideal for surface mount maintenance tasks, assembling components ranging from 0.2mm to 25mm in height with high efficiency and precision. Whether replacing a faulty component or upgrading an existing system, this service ensures seamless operation.

Surface Mount Technology Assembly Service: Businesses looking to apply surface mount technology (SMT) in their manufacturing process can benefit from Jettron’s SMT assembly service. We have no minimum order quantity restrictions, and Jettron Circuits Co., Ltd.’s daily supply capacity of 1,000 pieces can meet your needs, regardless of the quantity you need, and guarantee a delivery time of 15-20 working days.

In addition, the SMT assembly service also provides advanced testing options such as flying probe testing and X-ray inspection to ensure that each assembled circuit board meets the highest quality and reliability standards.

.

Customization:

Product Customization Services for the SMT Assembly Service:

Brand Name: JIETENG

Model Number: SMT Assembly Service

Place of Origin: China Shenzhen

Certification: UL

Minimum Order Quantity: 5pcs

Price: 12~60 USD

Delivery Time: 15-20 working days

Supply Ability: 1000pcs/day

Components Type: BGA, QFN, SOP, PLCC, SOIC, Etc.

Components: Passive And Active Components

Surface Finish: Immersion Gold

Lead Time: 15-20 Days

Product Name: SMT Assembly Service

FAQ:

Q. What information is needed for PCB quotation?

A: Gerber files and technical requirements. Such as PCB material, thickness, copper surface, color of mask and silk screen, etc. )

Q. What file formats are accepted for PCB production?

A: Gerber files: CAM350 PCB files: Protel 99SE, PADS, CAD, Altium Designer.

Q. Are my files safe?

A: Your files are completely safe. We protect our customers' intellectual property rights throughout the process. All files of customers will never be shared with any third party.

Q. What is the minimum order quantity?

A: Our company does not have a minimum order quantity. We are able to flexibly handle small and large batches.

Q. How much is the shipping cost?

A: The shipping cost depends on the destination, weight, and packaging size of the goods. If you need us to give you a quote, please let us know.
