4-Layer High Frequency PCB Precise Impedance Control Communication Immersion Gold 2U
| Place of Origin | China Shenzhen |
|---|---|
| Brand Name | JIETENG |
| Certification | UL IATF16949 |
| Model Number | High Frequency PCBs |
| Minimum Order Quantity | Negotiable |
| Price | Negotiable |
| Packaging Details | Blank carton, vacuum packed |
| Delivery Time | 17-20working days |
| Payment Terms | T/T, Western Union, |
| Supply Ability | 50㎡/day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Board Thickness | 1.88mm | Layer | 4 |
|---|---|---|---|
| Impedance Control | ±10% | Copper Thickness | 1OZ |
| Packaging | Vacuum Packing, Bubble Bag, Carton Box, Etc. | Min Trace Width/Space | 4/4mil |
| Solder Mask Color | Green | Silk Screen Color | White |
| Surface Finishing | ENIG,Immersion Gold | ||
| Highlight | 2U High Frequency PCB,4 Layer High Frequency PCB,Precise Impedance Control High Frequency PCB |
||
Product Description
Product Description:
Our high-frequency printed circuit boards are made of premium materials, using a mix of Rogers4350B and FR4 to ensure optimal performance and durability. Impedance control is one of the most critical factors in producing high-frequency PCBs, and the PCBs have a ±10% tolerance, which ensures that the PCBs provide consistent and reliable performance even in the most demanding applications. In addition to impedance control, surface treatment is another key factor in producing high-frequency PCBs. Our PCBs are finished with ENIG, which provides excellent conductivity and corrosion resistance. High-frequency PCBs are reliable and cost-effective solutions for applications such as telecommunications, wireless networks, and radar systems.
Technical Parameters:
| Product Attribute | Value |
| Product Name | High Frequency PCBs |
| Surface Finish | ENIG |
| Material | Rogers4350B, FR4 |
| Packaging | Vacuum Packing, Bubble Bag, Carton Box, Etc. |
| Copper Thickness | 1OZ |
| Min Trace Width/Space | 4/4mil |
| Min Hole Size | 0.25mm |
| Board Thickness | 1.88mm |
| Solder Mask Color | Green |
| Silk Screen Color | White |
| Impedance Control | ±10% |
Applications:
These high-frequency printed circuit boards can be used in a variety of applications and have a wide range of uses. For example, they are ideal for use in the telecommunications industry, the medical industry, for high-speed data transmission, high-frequency signal processing, and other applications that require high-speed and high-frequency circuits. They are also used in high-performance computing, where speed and precision are key. They are also ideal for aerospace and defense, where reliability and stability are critical.
Customization:
Our supply capacity is 50 ㎡/day, and we deliver products within 17-20 working days. We have an engineering team with more than 10 years of professional R&D experience. We can customize the products you need according to your drawings and process requirements, which fully meet the functions, performance, etc.
FAQ:
Q. What information is needed for PCB quotation?
A: Gerber files and technical requirements. Such as PCB material, thickness, copper surface, color of mask and silk screen, etc. )
Q. What file formats are accepted for PCB production?
A: Gerber files: CAM350 PCB files: Protel 99SE, PADS, CAD, Altium Designer.
Q. Are my files safe?
A: Your files are completely safe. We protect our customers' intellectual property rights throughout the process. All files of customers will never be shared with any third party.
Q. What is the minimum order quantity?
A: Our company does not have a minimum order quantity. We are able to flexibly handle small and large batches.
Q. How much is the shipping cost?
A: The shipping cost depends on the destination, weight, and packaging size of the goods. If you need us to give you a quote, please let us know.
