8-Layer White HASL Prototype PCB Assembly With 0.1mm Min Annular Ring / 1oz Copper Weight PTFE High Frequency Board

Place of Origin China
Brand Name JTETENG
Model Number PCB circuit board
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Blank carton, vacuum packed
Delivery Time 5-8 working day
Payment Terms Negotiable
Supply Ability 360000 square meters / year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Min Annular Ring 0.1mm Silkscreen Color White, Black, Yellow, Green
PCB Layer 6-Layer Surface Finish HASL
Min Hole Size 0.2mm PCB Size 100mm*100mm
Copper Weight 1oz Product Name Prototype PCB Assembly
Minimum Trace/Space 0.1mm Layer Count 8 Layer
Application Electronics Device Operating Temperature -55°C To +150°C
Keyword Custom PCB Printing Certifications ISO9001, UL, RoHS
Outer Cu Weight 0.5-4 0z Soldermask White
Copper Thickness 0.5-6.0oz Drilling Size Min 0.0078”(0.2mm)
Solder Mask Green. Red. Blue. White. Black.Yellow Number Of Layers 1-60L
Min Space 0.075mm
High Light

1oz Copper Prototype PCB Assembly

,

8 Layer Prototype PCB Assembly
